Single wires UL/CSA, UL Litzen und Drähte mit erhöhter Wärmebeständigkeit
Single wires UL/CSA, PTFE, FEP, ETFE

UL Style 1371 silver plated

Properties

Construction technical data Properties Colours

Construction

Conductor:

silver plated copper acc. to EN13602

Core Isulation:

PTFE - 5Y

Color code cores:

unicolour or bicolour in 4 sectors

technical data

Wall thickness:

0,20 mm

Temperature range static:

0 to 105 °C

Temperature range moved:

0 to 105 °C

100 MOhm x km bei 20°C (min. )

good ozone resistance
good weather resistance
good UV resistance
resistant against acids, oils and chemicals

Einfarbig

According to the application of the cables, wires and single cores, the color of the core insulation has to be designed differently according to the applicable standards. An overview of possible colors and the associated color codes can be found here.

AWG	Stranding	Core ∅ (mm)	CU-Index	total weight kg/km	Article number	datasheet
28	7x0,127mm	0,70	0,90	1,80	5YSY287005	Datenblatt
26	7x0,160mm	0,79	1,40	2,00	5YSY267005	Datenblatt
24	7x0,200mm	0,90	2,30	3,60	5YSY247005	Datenblatt
18	19x0,254mm	1,67	9,60	13,50	5YSY189005	Datenblatt
