Copper round ropes bare

Construction technical data Properties

Construction

Conductor:

bare copper acc. to EN 13602

Core Isulation:

without insulation

Approval:

in acc. to DIN 46438

technical data

Cross sectional area m²	Stranding	CU-Index	Article number	datasheet
1,50	385x0,07mm	15,00	4R15007	Datenblatt
2,50	651x0,07mm	25,00	4R25007	Datenblatt
3,00	798x0,07mm	30,00	4R30007	Datenblatt
4,00	1036x0,07mm	40,00	4R40007	Datenblatt
6,00	1575x0,07mm	60,00	4R60007	Datenblatt
10,00	2562x0,07mm	100,00	4R10107	Datenblatt
16,00	4116x0,07mm	160,00	4R16107	Datenblatt
25,00	3234x0,10mm	250,00	4R25110	Datenblatt
35,00	4508x0,10mm	350,00	4R35110	Datenblatt
50,00	6468x0,10mm	500,00	4R50110	Datenblatt
70,00	8967x0,10mm	700,00	4R70110	Datenblatt
95,00	12201x0,10mm	950,00	4R95110	Datenblatt
